HIGH LEVEL OF SAFETY

Safet y considerations have required designing a braking mechanism with dual safety circuit, also 2H2SP series meet strict safety regulations related to elevator design and installation defined in PN- EN 81-1+A3:2009 standards.

  FEATURES

·         Braking torque: 2x4 ÷ 2x1600 Nm
·         12 mechanical sizes
·         Supply voltage: 24, 104, 180, 207 V DC
·         Possible level of protection: IP44 ÷ IP56
·         Thermal class F (155°C)
·         Spring actuated and electromagnetically released
·         Braking torque can be reduced
·         Manual release facilities for all sizes
·         Air gap and wear monitoring (optional)

THEY ARE DESIGNED FOR BRAKING ROTATING PARTS OF MACHINES AND THEIR TASK IN

 ·         Emergency stopping, in order to ensure drive safety functions
 ·         Immobilizing machine actuators, acting as a positioning device
 ·         Minimizing run-on times of drives

  APPLICATION AREAS

·         Drives of personal lifts
·         Platforms
·         Warehousing
·         Cranes
·         and wherever one has to keep in mind strict regulations of technical supervisory authorities applicable to elevator equipment

To download the catalogue click HERE
